Digital UHF Wireless Receiver - PE [2026]

Based on the DT220 TECH PLUS platform. Code: PE (Performance). Cross T-Diversity,530-590Mhz / 640-700Mhz. 2CH/ 4CH. for Performance Scenarios & Acoustic Measurement!

List price： $0.00

Price : $0.00

MemberPrice：

Ordinary： $100.00-140.00

VIP： $100.00-140.00

Shipping Weight [Related with size]:0.000KG

Channel：

Freq. Band：

Quantity:

Buy Now

Add to Cart

Product

Based on the DT220 TECH PLUS platform. Code: PE (Performance). Cross T-Diversity,530-590Mhz / 640-700Mhz. 2CH/ 4CH. for Performance Scenarios & Acoustic Measurement!

DT248R-2/4PE-5359/6470

2/4 Channel Digital UHF Wireless Receiver [PE]

[530-590Mhz / 640-700Mhz]

Application Scenarios

1. In Performance scenarios, replace the cable of wired microphone;

2. Used for pickup and forwarding of various sound sources (instruments, harmony, chorus) on stage;

4. Acoustic Measeurement.

Characteristic

. Machine Code : PE (Performance)

. Digital audio UHF wireless technology.

. 500MHz and 600MHz frequency bands with Multi-filters Auto-Swapable Circuit.

. 2 ANT Cross backup mode ture diversity.

. PSK modulation.

. OLED color screen, rich functions.

. Supports Acoustic Measurement.

Paramsters

	Communication Parameters
	Freq. Band	530~590MHz (5359) / 640~700MHz (6470)
	Modulation Mode	PSK
	Effective Bit	20bit
	Sampling Rate	48K
	Transmission Distance	70m (varies according to the transmitter) (related to the transmitter model, RF signal absorption, reflection, interference and performance options)
	Transmission Concurrency	24 simultaneous transmissions / 60Mhz
	S/N	>120dB
	Dynamic	>120dB
	Freq. Response	20Hz-20KHz (Attenuation<3dB)
	Phase Response	30°-60° (Related to the whole system, including sound cards, mixer, cables, etc.)
	Transmission Delay	4.17 ms
	Distortion T.H.D	<0.03% （@1KHz）
	Sound Parameters
	Mic Type	-
	Sensitivity	-
	Freq. Response	-
	Output Impedance	-
	Directivity	-
	Physical and Electrical Indicators
	Power Supply	DC 12V&1A 5W
	Power Supply	DC 12V&1A 5W
	Power Interface	5.5 mm interface
	Endurance	-
	Size	2CH RX: 480mm200mm45mm (1U) ( without antenna) / 2050g 2CH RX: 480mm200mm45mm (1U) ( without antenna) / 2150g
	Launch Connector	XLR Interface
	Function	External antenna*2, wireless channel scanning

Questions Frequently Asked

1. When multiple devices are used simultaneously, improper frequency setting can easily lead to performance degradation due to intermodulation interference.
